York D2HE/D2HG060 - Manual (Page 21)

036-21216-003-A-0204
Unitary Products Group 21
FIGURE 12 - DETAIL “B” UNIT WITH FIXED OUTDOOR AIR/MOTORIZED DAMPER RAINHOOD
2 7 - 1 / 2 7 - 1 / 4
2 7 - 1 / 2
1 9 - 1 / 8
" A " 4 4 - 7 / 8
4 - 3 / 8
3 - 1 / 2
8 - 1 / 4
1 0 - 1 / 4
L . H . E N D V I E W R E A R V I E W
D I M E N S I O N " A "
F I X E D
O U T D O O R
A I R D A M P E R
1 2
M O T O R I Z E D
D A M P E R 1 6 - 1 / 2
FIGURE 13 - UNIT AND CURB APPLICATION
BASE RAIL 3.56"
3.69"
