036-21216-003-A-0204
10 Unitary Products Group
TABLE 8: COOLING CAPACITIES - MODELS DHE/DHG060
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
85°F 95°F
TOTAL
CAP. 1
MBH
POWER
INPUT 2
SENSIBLE CAPACITY 3
TOTAL
CAP.
1
MBH
POWER
INPUT
2
SENSIBLE CAPACITY
3
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
86 83 80 77 74 71 68 86 83 80 77 74 71 68
2500
72 82 4.3 56 50 43 37 30 - - 76 4.6 54 48 41 34 28 - -
67 70 4.2 67 61 54 48 41 34 28 65 4.5 65 58 51 45 38 31 25
62 67 4.0 67 67 66 59 52 46 39 62 4.5 62 62 62 55 49 42 35
57 66 4.0 66 66 66 59 52 46 39 61 4.4 61 61 61 54 47 41 34
2250
72 78 4.3 53 47 41 35 29 - - 73 4.6 50 44 38 32 26 - -
67 67 4.2 63 57 51 45 39 33 27 62 4.5 60 54 48 42 36 30 24
62 64 4.0 64 64 62 56 50 44 38 60 4.4 60 60 59 53 47 41 35
57 63 4.0 63 63 63 57 51 45 39 58 4.4 58 58 58 52 46 40 34
2000
72 75 4.3 49 43 38 33 27 - - 70 4.6 46 41 36 30 25 - -
67 64 4.2 58 53 48 42 37 32 26 60 4.5 56 50 45 39 34 29 23
62 61 4.0 61 61 58 52 47 42 36 57 4.4 57 57 55 50 45 39 34
57 60 4.0 60 60 59 54 49 43 38 56 4.4 56 56 56 50 45 39 34
1750
72 72 4.3 44 40 35 30 25 - - 67 4.6 43 38 33 28 24 - -
67 62 4.2 53 49 44 39 34 30 25 58 4.5 51 46 41 37 32 27 22
62 59 4.0 59 57 53 48 44 39 34 55 4.4 55 54 51 46 42 37 32
57 58 4.0 58 57 55 50 45 40 36 54 4.4 54 54 51 47 42 37 32
1500
72 69 4.2 40 36 32 28 24 - - 65 4.6 39 34 30 26 22 - -
67 59 4.1 48 44 40 36 32 28 23 56 4.5 46 42 38 34 30 26 21
62 56 4.0 56 53 49 44 40 36 32 53 4.4 53 51 47 43 39 35 30
57 55 4.0 55 54 50 46 42 37 33 52 4.4 52 51 47 43 39 35 30
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
105°F 115°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
SENSIBLE CAPACITY
3
TOTAL
CAP.
1
MBH
POWER
INPUT
2
SENSIBLE CAPACITY
3
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
86 83 80 77 74 71 68 86 83 80 77 74 71 68
2500
72 68 5.0 51 44 38 31 25 - - 61 5.3 48 41 35 28 21 - -
67 60 4.8 60 55 49 42 35 29 22 55 5.1 55 53 46 39 33 26 20
62 56 4.8 56 56 56 49 43 36 29 50 5.1 50 50 50 43 37 30 23
57 55 4.7 55 55 55 48 42 35 28 49 5.0 49 49 49 43 36 29 23
2250
72 67 4.9 48 42 36 30 24 - - 60 5.3 45 39 33 27 21 - -
67 58 4.8 57 52 46 40 34 28 22 54 5.1 53 50 44 38 32 26 20
62 55 4.7 55 55 54 48 42 36 30 49 5.0 49 49 49 43 37 31 25
57 54 4.7 54 54 53 47 41 35 29 49 5.0 49 49 49 43 37 31 25
2000
72 65 4.9 44 39 33 28 23 - - 60 5.2 42 36 31 26 20 - -
67 57 4.8 54 48 43 38 32 27 22 54 5.1 52 47 41 36 30 25 20
62 53 4.7 53 53 52 46 41 36 30 49 5.0 49 49 48 43 37 32 26
57 52 4.7 52 52 52 46 41 36 30 48 5.0 48 48 48 42 37 32 26
1750
72 62 4.9 40 35 31 26 21 - - 56 5.2 38 33 28 24 19 - -
67 54 4.8 49 44 40 35 30 25 21 51 5.0 47 42 38 33 28 23 19
62 51 4.7 51 50 48 43 38 33 29 46 5.0 46 46 44 39 34 30 25
57 50 4.6 50 50 48 43 38 33 29 46 4.9 46 46 44 39 34 29 25
1500
72 59 4.9 36 32 28 24 20 - - 53 5.2 34 30 26 22 18 - -
67 52 4.7 44 40 36 32 28 24 20 48 5.0 43 38 34 30 26 22 18
62 48 4.7 48 47 43 39 35 31 27 43 4.9 43 43 40 36 32 27 23
57 47 4.6 47 47 43 39 35 31 27 43 4.9 43 43 40 36 31 27 23
1. These capacities are gross ratings. For net capacity, determine the KW of the supply air blower motor from the Blower Performance
Table, multiply this value by 3.415 MBH / KW to determine the motor heat, and deduct this heat from the gross capacity of the unit
2. These ratings include the compressor and the condenser fan motors but not the supply air blower motor. The total condenser fan
motor power input is 0.36kW. Refer to Tables 10 and 11 for the kW of the supply air blower motor.
3. These capacities are gross ratings. For net capacity, determine the kW of the supply air blower from Tables 10 and 11, multiply
this value by 3.415 MBH/kW to determine the motor heat, and deduct this heat from the gross capacity of the unit.
NOMINAL RATING ALL SENSIBLE CAPACITY
