Xerox SquareFold Trimmer User Manual
Page 16

User Guide
12
Overview
SquareFold Trimmer Module
The following table shows various scenarios using different paper weights, media types, and trim setting selections. Use
this table as a guideline when selecting a trim setting for your specific job.
The settings shown in the following table
are provided as examples and are not meant to represent every possible job scenario; again, use this table as a
guideline only.
Scenario
number
1
Paper Size
Finished booklet
size
Paper weight
(lbs./g/m²)
Approximate Trim
setting (mm)
Number of
pages in finished
booklet
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
20 lbs./75g/m²
130
20
2
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
24 lbs./90 g/m²
125
14
3
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
32 lbs./120 g/m²
135
10
4
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
20 lbs./75g/m²
125
10
5
8.5 x 11 in./A4 (210 x
297 mm)
5.5 x 8.5 in./149 x 210
mm
80 lbs./120 g/m²
135
12
6
8.5 x 14 in./B4 (250 x
353 mm)
8.5 x 7 in./250 x 176.5
mm
20 lbs./75g/m²
172
6
8
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
24 lbs./90 g/m²
200
14
10
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
20 lbs./80 g/m²
210
22
7
8.5 x 14 in./B4 (250 x
353 mm)
8.5 x 7 in./250 x 176.5
mm
24 lbs./90 g/m²
170
6
9
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
80 lbs./216 g/m²
205
5
11
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
24 lbs./90 g/m²
210
8
12
11 x 17 in./A3 (297 x
420 mm)
8.5 x 11 in./A4 (210 x
297 mm)
80 lbs./120 g/m²
205
10
13
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm
80 lbs./120 g/m²
220
6
14
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm
80 lbs./216 g/m²
215
5
15
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm
80 lbs./210 g/m²
210
4
16
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm
28 lbs./ 105 g/m²
220
16
17
12 x 18 in./305 x 458
mm
6 x 9 in./152 x 229 mm
80 lbs./120 g/m²
210
14
