Default Parameter Settings
Print Setup 78
P1003636-002 TTP 7030™ Technical Manual 10/05/2009
Carriage Return and Line Feed can be interpreted in five different ways to suit different
operating systems.
Decides if the printer should cut after executing an FF command, or if it should just feed the
form length.
When enabled, marks on the paper set the form length. Minimum one form length is always
fed. If a black mark is found before that, the printer feeds to the next black mark, then cuts and
ejects. This ensures that no small paper stripes are cut of and left in the printer. Note that this
parameter is used when loading paper and when pressing the Feed button. So even if black
mark is enabled in the Windows driver and works, parameters for black mark must be set up
correctly.
33
0 Default
CR/LF Behavior*
*. v=0 is suitable for Windows, v=1 for UNIX, v=2 for DOS, and v=4 for Macintosh
0 Min
4 Max
&P<33><0>
LF = CR/LF CR = Ignored
&P<33><1>
LF = CR/LF CR = CR
&P<33><2>
LF = LF CR = CR
&P<33><3>
LF = LF CR = CR/LF
&P<33><4>
LF = Ignored CR = CR/LF
Note • The character currently interpreted as LF converts text from the input buffer to pixels
on the paper.
34
1 Default
Auto Cut After FF 0 Min
2 Max
&P<34><0>
No cut
&P<34><1>
Cut
&P<34><2>
Forced cut at black mark (cuts directly when a black mark is
detected). This works only if black mark mode is selected
(n36=2).
35
0 Default
Black Mark Mode 0 Min
1 Max
&P<35><0>
Normal
&P<35><1>
Black mark synchronization enabled
