47 Programming
Graphics Commands
10/05/2009 TTP 7030™ Technical Manual P1003636-002
Prints a customized logotype 2 stored in the flash PROM. See also
Logotypes on page 66
.
Prints a customized logotype stored in the flash PROM at the position of the cursor. The
bottom line of the logotype is positioned at the baseline of the text on the line. If the logotype
is higher than the text, the line spacing is increased.
See also Logotypes on page 66 .
ESC g n1...n5
Print Logotype
1B 67 n1...n5 hex
27 103 n1...n5 decimal
2. For logotype loading, see ESC & 1 on page 53 .
n1 One-byte logotype identification No. (0—15)
n2n3 Two-byte definition of desired print position in X-direction measured
from left-hand edge of the page (see
Printable Area on page 86
regarding
definition of “page”). X-direction is perpendicular to the paper transport
direction.
n4n5 Two-byte definition of desired print position in Y-direction. In variable
document mode the Y-position is ignored. The resolution is 0.125mm in
both X and Y directions
ESC L n1
Print Logotype at Current Position
1B 4C n1 Hex
27 76 n1 Decimal
n One-byte logotype identification No. (0—15)
