Specifications
Bar Codes (Non-Windows Applications) 110
P1003636-002 TTP 7030™ Technical Manual 10/05/2009
Bar Codes (Non-Windows Applications)
Paper Handling
Orientation Horizontal and vertical
Symbology EAN, UPC, Interleaved 2-of-5, ISBN, Code39, and Code 128
Add-on 2, or 5 digit add-on can be added to EAN, UPC codes
5 digit add-on can be added to ISBN
Paper width 80 mm or 112 mm depending on model
Printout length 75–500 mm before partially ejecting printout. No upper limit
for printout length. (112-500mm for Retract-and-retain
versions of the printer)
Cutting Guillotine cutter
Presenter operation Stores the printout until it is fully printed and cut, then
presents part of the printout to the customer. When the
customer pulls the ticket, a sensor reacts on the pull and feeds
out the full printout. Extremely long printouts can be partially
ejected to limit loop buildup.
Eject length after cut Programmable eject length. Full eject, or printout held until
the customer removes it. Eject of uncollected printouts.
Printout retraction Optional retract and retain function pulls back uncollected
printouts and throws them in a wastebasket inside the kiosk.
Paper loading Automatic feed, cut, and eject when paper is detected.
Automatic "on-line" after successful paper load.
Automatic synchronization to Top-of-form marks when
black-mark mode is selected in the parameter setup.
Sensors Optical sensors: Out of paper, paper left in presenter, paper
pulled, paper near end (optional) and weekend level sensor
(optional).
Switch sensors: Cutter not in home position and print head
lifted.
