Programming
Barcode Commands 40
P1003636-002 TTP 7030™ Technical Manual 10/05/2009
Barcode Commands
TTP 7030 can print EAN 8, EAN 13, EAN128, UPC, 2-of-5 Interleaved, ISBN, Code39 and
Code128 barcodes with it’s standard firmware. A special firmware is available where the
barcodes are replaced with the PDF 417 2D barcode. See
Firmware on page 104
, and PDF417
command.
Code 128 / EAN128
The following codes select function codes in Code 128:
Example • The example below will print an EAN barcode with height = 10 mm, 15 mm in
from the right margin.
BS<0><0><78><0><0><0><50h><0><2>0h> (hex)
BW<0>733104000099<0> (hex) 

Name Dec Hex
FNC1 193 C1
FNC2 194 C2
FNC3 195 C3
FNC4 196 C4
