39 Programming
Text Commands
10/05/2009 TTP 7030™ Technical Manual P1003636-002
Executes the number of linefeeds as defined by variable n1. The length of each line feed is
determined by the default value for selected font (see parameter
13 on page 77 ).
The print position is returned to the beginning of the line. Any text on the line is lost. To avoid
losing text, send an before sending d.
Prints data from the input buffer and feeds the paper to the top of the next page.
In fixed document length (FORM-mode) this command prints data in the input buffer and
feeds the paper to the top of next page.
In variable document length mode advances to the minimum page length. If the printout
already is longer than the minimum page length, does not feed the paper at all.
In black-mark mode, the command looks for a black mark, see Z
If "Auto cut" is set to 1 (see
Auto Cut After FF on page 78
), effect form-feed, cut, and
eject.
Shifts the current print position to the next Tab position.
Set tab positions with parameters p15 – p30.
ESC d n1
Make n Linefeeds
1B 64 n1 hex
27 100 n1 decimal
FF
Form Feed 0C hex
12 decimal
Note •
Use parameter p37 and p38 to define page length.
HT
Horizontal Tabulation 09 hex
9 decimal
