ExpWave 240B Secure Outdoor Ethernet Radio Link
15-4 IP Policy Routing
FIELD DESCRIPTION
Len Comp Press [SPACE BAR] and then [ENTER] to choose from Equal, Not Equal,
Less, Greater, Less or Equal or Greater or Equal.
Source
addr start / end Source IP address range from start to end.
port start / end Source port number range from start to end; applicable only for TCP/UDP.
Destination
addr start / end Destination IP address range from start to end.
port start / end Destination port number range from start to end; applicable only for TCP/UDP.
Action Specifies whether action should be taken on criteria Matched or Not Matched.
Gateway addr Defines the outgoing gateway address. The gateway must be on the same
subnet as the EXPWAVE if it is on the LAN, otherwise, the gateway must be
the IP address of a remote node. The default gateway is specified as 0.0.0.0.
Type of Service Set the new TOS value of the outgoing packet. Prioritize incoming network
traffic by choosing No Change, Normal, Min Delay, Max Thruput, Max
Reliable or Min Cost.
Precedence Set the new outgoing packet precedence value. Values are 0 to 7 or No
Change.
Log Press [SPACE BAR] and then [ENTER] to select Yes to make an entry in the
system log when a policy is executed.
When you have completed this menu, press [ENTER] at the prompt “Press [ENTER] to confirm or [ESC] to
cancel” to save your configuration or press [ESC] to cancel and go back to the previous screen.
15.5 Applying an IP Policy
This section shows you where to apply the IP policies after you design them.
15.5.1 Ethernet IP Policies
From Menu 3 – Ethernet Setup, type 2 to go to Menu 3.2 – TCP/IP and DHCP Ethernet Setup.
You can choose up to four IP policy sets (from 12) by typing their numbers separated by commas, for example, 2, 4, 7,
9.
Figure 15-6 Menu 3.2 — TCP/IP and DHCP Ethernet Setup
Menu 3.2 - TCP/IP and DHCP Ethernet Setup
DHCP= Server
Configuration:
Client IP Pool Starting Address= 192.168.1.33
Size of Client IP Pool= 32
Primary DNS Server= 0.0.0.0
Secondary DNS Server= 0.0.0.0
DHCP Server Address= N/A
TCP/IP Setup:
IP Address= 192.168.1.1
IP Subnet Mask= 255.255.255.0
RIP Direction= Both
Version= RIP-1
IP Policies= 2,4,7, 9
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
Type IP Policy
sets,
separated by
commas.
