ExpWave 240B Secure Outdoor Ethernet Radio Link

9-2

Filter Setup

9.2 Configuring a Filter Set

To configure a filter sets, follow the procedure below:

Step 1. Select option 21. Filter Set Configuration from the Main Menu to open Menu 21.

Figure 9-2 Menu 21 - Filter Set Configuration

Step 2. Select the filter set you wish to configure (no. 1-12) and press [Enter]

Step 3. Enter a descriptive name or comment in the Edit Comments field and press Enter.

Press [Enter] at the message: [Press ENTER to confirm] to open Menu 21.1 - Filter Rules Summary.

Figure 9-3 Menu 21.1 - Filter Rules Summary

9.3 Filter Rules Summary Menu

This screen shows the summary of the existing rules in the filter set. The following tables contain a brief description
of the abbreviations used in Menu 21.1.

Table 9-1 Abbreviations Used in the Filter Rules Summary Menu

Abbreviations Description

Display

Refers to the filter rule number (1-6).

Refers to Active.

[Y] means the filter rule is active.
[N] means the filter rule is inactive.

Type

Refers to the type of filter rule.
This shows GEN for generic, IP for
TCP/IP

[GEN] for Generic
[IP] for TCP/IP

Filter Rules

The filter rule parameters will be
displayed here (see below).

Refers to More.

[Y] means there are more rules to check.

Menu 21.1 - Filter Rules Summary

# A Type Filter Rules M m n

- - ---- -------------------------------------------- --------- - - -

1 Y IP Pr=17, SA=0.0.0.0, DA=0.0.0.0, DP=53 N D F

2 Y

3 Y

4 Y
5 Y

6 Y

Enter Filter Rule Number (1-6) to Configure:

Menu 21 - Filter Set Configuration

Filter

Set #
------

5
6

Comments

------------------

______________

______________
______________

Filter

Set #
------

11
12

Comments

------------------

______________

______________
______________

Enter Filter Set Number to Configure= 0

Edit Comments=

Press ENTER to CONFIRM or ESC to CANCEL:
