ExpWave 240B Secure Outdoor Ethernet Radio Link
Wireless Setup 5-5
FIELD DESCRIPTION EXAMPLE
DNS Server
DHCP Server
Address
If Relay is selected in the DHCP field above, then type the IP address of
the actual, remote DHCP server here.
Follow the instructions in the following table to configure TCP/IP parameters for the LAN port.
Table 5-4 LAN TCP/IP Setup Menu Fields
FIELD DESCRIPTION EXAMPLE
TCP/IP Setup:
IP Address Enter the IP address of your ExpWavein dotted decimal notation 192.168.1.1
(default)
IP Subnet Mask Your ExpWavewill automatically calculate the subnet mask based
on the IP address that you assign. Unless you are implementing
subnetting, use the subnet mask computed by the ExpWave. 255.255.255
.0
RIP Direction Press [SPACE BAR] and then [ENTER] to select the RIP direction.
Options are: Both, In Only, Out Only or None. Both
(default)
Version Press [SPACE BAR] and then [ENTER] to select the RIP version.
Options are:
RIP-1, RIP-2B or RIP-2M. RIP-1
(default)
IP Policies You can apply up to four IP Policy sets (from twelve) by typing their
numbers separated by commas. 2,7,9,11
When you have completed this menu, press [ENTER] at the prompt [Press ENTER to Confirm…] to save
your configuration, or press [ESC] at any time to cancel.
