ExpWave 240B Secure Outdoor Ethernet Radio Link
IP Policy Routing 15-3
ABBREVIATION MEANING
P IP layer 4 protocol number (TCP=6, UDP=17…)
T Type of service of incoming packet
PR Precedence of incoming packet
Action
GW
Gateway IP address
T Outgoing Type of service
P Outgoing Precedence
Service
NM
Normal
MD Minimum Delay
MT Maximum Throughput
MR Maximum Reliability
MC Minimum Cost
Type a number from 1 to 6 to display Menu 25.1.1 – IP Routing Policy (see the next figure). This menu allows you to
configure a policy rule.
Figure 15-5 IP Routing Policy
Table 15-2 IP Routing Policy
FIELD DESCRIPTION
Policy Set Name This is the policy set name assigned in Menu 25 – IP Routing Policy Setup.
Active Press [SPACE BAR] and then [ENTER] to select Yes to activate the policy.
Criteria
IP Protocol Enter a number that represents an IP layer 4 protocol, for example, UDP=17,
TCP,=6 ICMP=1 and Don’t care=0.
Type of Service Prioritize incoming network traffic by choosing from Don’t Care, Normal, Min
Delay, Max Thruput or Max Reliable.
Precedence Precedence value of the incoming packet. Press [SPACE BAR] and then
[ENTER] to select a value from 0 to 7 or Don’t Care.
Packet Length Type the length of incoming packets (in bytes). The operators in the Len Comp
(next field) apply to packets of this length.
Menu 25.1.1 - IP Routing Policy
Policy Set Name= test
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Normal Packet length= 40
Precedence = 0 Len Comp= N/A
Source:
addr start= 1.1.1.1 end= 1.1.1.1
port start= 20 end= 20
Destination:
addr start= 2.2.2.2 end= 2.2.2.2
port start= 20 end= 20
Action= Matched
Gateway addr = 192.168.1.1 Log= No
Type of Service= Max Thruput
Precedence = 0
Press ENTER to Confirm or ESC to Cancel:
