ExpWave 240B Secure Outdoor Ethernet Radio Link
11-4 System Maintenance
11.3 Log and Trace
There are two logging facilities in the ExpWave. The first is the error logs and trace records that are stored locally.
The second is the UNIX syslog facility for message logging.
11.3.1 Viewing Error Log
The first place you should look for clues when something goes wrong is the error/trace log. Follow the procedure
below to view the local error/trace log:
Step 1. Select option 24 from the main menu to open Menu 24 - System Maintenance.
Step 2. From menu 24, select option 3 to open Menu 24.3 - System Maintenance - Log and Trace.
Step 3. Select the first option from Menu 24.3 - System Maintenance - Log and Trace to display the error log in
the system.
After the ExpWave finishes displaying, you will have the option to clear the error log.
Figure 11-6 Menu 24.3 — System Maintenance — Log and Trace
Examples of typical error and information messages are presented in the figure below.
Figure 11-7Examples of Error and Information Messages
11.3.2 UNIX Syslog
The ExpWave uses the UNIX syslog facility to log the CDR (Call Detail Record) and system messages to a syslog
server. Syslog and accounting can be configured in Menu 24.3.2 - System Maintenance - Unix Syslog, as shown
next.
Figure 11-8 Menu 24.3.2 - System Maintenance - UNIX Syslog
Menu 24.3 - System Maintenance - Log and Trace
1. View Error Log
2. UNIX Syslog
Please enter selection
No Name L ID T Fa Start_Time Cnt Message
1 PP05 7 8 17:27:58 03/30/03 1 Unknown PHY Type(ResetPhyChip)
2 PINI 7 8 17:27:58 03/30/03 1 main: init completed
3 PP12 7 8 17:28:03 03/30/03 1 adjtime task pause 1 day
4 PINI 7 8 17:37:40 03/30/03 1 SMT Session Begin
Clear Error Log (y/n):
Menu 24.3.2 - System Maintenance - UNIX Syslog
Syslog:
Active= No
Syslog IP Address= ?
Log Facility= Local 1
Types:
Firewall log= No
Press ENTER to Confirm or ESC to Cancel
