Zebra Technologies ZEBRA RXI4TM User Manual
Page 49
49
Operations
Load Media in Peel-Off Mode
1/7/10
Xi4™/RXi4™ User Guide
P1009874-002
To set up the printer in Peel-Off mode, complete these steps:
1.
Remove the rewind plate (if installed) from the front of the printer. Store it on the two
mounting screws on the inside of the printer base.
2.
Set the printer to Peel-Off mode. See
for instructions.
3.
Insert media into the printer. See
Prepare the Media for Loading on page 39
for
instructions.
Caution • While performing any tasks near an open printhead, remove all rings, watches,
hanging necklaces, identification badges, or other metallic objects that could touch the
printhead. You are not required to turn off the printer power when working near an open
printhead, but Zebra recommends it as a precaution. If you turn off the power, you will lose
all temporary settings, such as label formats, and you must reload them before you resume
printing.
