Zebra Technologies ZEBRA RXI4TM - Manual (Page 24)

Printer Setup
Select a Data Communication Interface 24
P1009874-002 Xi4™/RXi4™ User Guide 1/7/10
IEEE 1284
Bidirectional Parallel Standard Limitations and Requirements
• Maximum cable length of 10 ft (3 m).
• Recommended cable length of 6 ft (1.83 m).
• No printer parameter changes required to match the host
computer.
Connections and Configuration No additional
configuration is necessary. An Ethernet print server (if installed)
takes up or covers this port on the printer.
USB Standard Limitations and Requirements
• Maximum cable length of 16.4 ft (5 m).
• No printer parameter changes required to match the host
computer.
Connections and Configuration No additional
configuration is necessary.
Caution • Be careful not to plug the USB cable into the wired
Ethernet print server connector on the printer because doing so
will damage the connector.
Table 3 • Data Communication Interfaces (Continued)
Interface
Standard or
Optional
Description
