Specifications
Media Specifications 172
P1009874-002 Xi4™/RXi4™ User Guide 1/7/10
140Xi4, 170Xi4, and 220Xi4 Black Mark Sensing
Media Specifications 140Xi4 170Xi4 220Xi4
Mark length
(measuring parallel to label or tag
edge) Minimum 0.12 in. (3 mm) 0.12 in. (3 mm) 0.12 in. (3 mm)
Maximum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Mark width (measuring to
perpendicular label or tag edge) Minimum 0.43 in. (11 mm) 0.43 in. (11 mm) 0.43 in. (11 mm)
Maximum Full media width Full media width Full media width
Mark location within 0.040 in. (1 mm) of
the inside media edge within 0.040 in. (1 mm) of
the inside media edge within 0.040 in. (1 mm) of
the inside media edge
Mark density in Optical Density Unit (ODU) >1.0 >1.0 >1.0
