A
A-11 Color Measurement Instruments
For a Mac OS computer, connect the 8-pin mini-DIN plug directly into the serial port
of the computer.
N OTE : For Mac OS computers with a USB port (for example, an iMac), you need an
adapter to connect the DTP32 to your computer. For information about supported
adapters, see the X-Rite, Inc. web site (www.x-rite.com).
4. Plug the small connector on the adapter cable into the side of the X-Rite DTP32 and
plug the AC adapter into a wall outlet.
5. Turn on the computer.
6. Calibrate the DTP32 (see the following section).
7. Calibrate the EX7750 using ColorWise Pro Tools and the DTP32 (see page 2-18 ).
Unused connector
Connect to serial port
AC adapter
Small connector
