75
ANTENNA/FEED ASSEMBLY
INDEX PART DESCRIPTION QTY
NO. NUMBER
2762827 46 cm Antenna/Feed Assembly
1 2745303 46 cm Reflector (18 inches), White 1
2 2160362 1/4-20 x 5/8" Carriage Bolt, White 4
3 2160696 E-Clip 1
4 2745287 Feed Support Arm, White 1
5 2780160 LNBF 1
6 2160353 1/4-20 x 1-1/4" Carriage Bolt 1
7 2753067 Coax Cable Assembly 1
8 2160821 Spring 1
9 2160170 10-32 x 1-1/8" Hex Head Bolt* 2
10 2160349 10-32 Washer 2
11 2745288 Reflector Backup, Cast, White 1
12 2160691 5/16" x 2.925 Round Head Pin 1
13 2160228 1/4-20 Hex Flange Lock Nut 5
14 2160024 1/4" Flat Washer 4
15 2190105 Cable Tie** 2
* Not included with the 2762827 Antenna/Feed Assembly.
** Not shown for clarity.
Rev. 11/99
