Text mode
Original mode

Az(X) = XXXXX
El (X) = XXXXX XXX

Signal Level - This will vary
according to received signal

Azimuth Count - Numbers changed
according to antenna position

Azimuth Stop Condition
(see note)

Elevation Stop Condition
(see note)

Figure 28

NOTE: There are five (5) motor stop conditions:

0 - Motor stopped under normal conditions.
1 - Motor stopped because a limit switch was encountered.
2 - Motor stopped because motor count limit was reached.
3 - Motor stopped because s button was pressed on the positioner.
4 - Motor stopped because of elevation/rotation constraints (antenna

was physically stopped by an obstruction or other obstacle).

Under normal conditions the stop conditions will be 0, 1, 2, or 3. If you get
number 4, refer to Troubleshooting section.
