33
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
PUTTING ANTENNA IN PARK POSITION
NOTE: All commands will be shown in bold with brackets, example
[SELECT A].
To put antenna in park (travel) position, proceed as follows:
1. Press [UP/DOWN] arrow until you get Park displayed on positioner
display. See Figure 23.
2. Press [SELECT A or B] Park to put antenna into park (travel) position. You
will get the message Collapsing System while antenna is moving to travel
position.
3. Step out of the RV/coach and verify that antenna is in the travel position
when Collapsing System is replaced with normal menu, Figure 24.
Figure 23
Figure 24
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
1. Press UP/DOWN arrow
buttons to get Park on
screen
2. Press SELECT A or B as
appropriate
Park
Move to Last Sat
Search DSS
Park
