27
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Figure 11
Figure 10
System has found a satellite and is fine tuning the signal
Fine Tuning
Elevation
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
7. Press SELECT A if correct satellite was found
Press SELECT B if correct satellite was not found
Correct Satellite
Continue Search
9. Verify that system has found correct satellite (you will see a picture). Since
DBS services use a digital signal and the satellites are only separated by 9
o ,
the system can find the wrong satellite. Press [SELECT A] if correct satellite
was found, Figure 11. You are now ready to watch satellite TV! If the wrong
satellite was found, press [SELECT B] to continue the search.
If no satellite is found the message Satellite Not Found, Press Any Button,
will be displayed by the positioner. Press any button to return to the menu
shown in Figure 1, page 4.
NOTE: If after two (2) tries you still get "Satellite Not Found" check that:
1. The antenna has a clear view of the satellite(s), no trees,
buildings, etc. blocking the view. The satellite signal will not pass
through solid objects.
2. Your receiver is turned ON.
3. The positioner is connected to the receiver correctly, refer to
Installation Manual.
If after checking the above, you still do not find a satellite refer to the
Troubleshooting Manual.
Rev. 2/97
