Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Figure 6
Figure 7
Figure 8
Figure 9
Positioner is setting appropriate detector level (amount of signal
required)
Positioner is moving antenna to start position
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
System is now searching for satellite
Searching (350)
Level = 238
System has found the satellite and is fine tuning antenna position
Fine Tuning
Azimuth
Setting Detector
Moving to Start
