13
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
NOTE: All commands will be shown in bold with brackets, example
[SELECT A].
11. Plug positioner into AC receptacle.
12. Press [UP/DOWN] arrow until you get Park displayed on positioner
display. See Figure 14.
13. Press [SELECT A or B] Park to put antenna into park (travel) position. See
Figure 14. The positioner will display Collapsing System while antenna is
moving to travel position.
14. Verify that antenna is in the travel position (see Figures 2 and 3) when
Collapsing System is replaced with normal menu, Figure 15.
Figure 14
Figure 15
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
1. Press UP/DOWN arrow
buttons to get Park on
screen
2. Press SELECT A or B as
appropriate
Park
Move to Last Sat
Search DSS
Park
You are now ready to enjoy satellite TV! Refer to Operation Manual on
how to acquire the satellite signal.
Rev. 6/98
