28
One requirement must be met to fully enjoy automatic system TV viewing.
The RV must be reasonably level. Any of the leveling indicators available
should be adequate for this purpose. If the RV is not leveled, the system
may not find the high power satellites.
After the RV has been leveled, proceed as follows:
To find the satellite by entering the elevation angle for your location, proceed
as follows:
1. Turn TV ON and tune to channel 3 or 4 (output channel of receiver).
2. Press [POWER] on receiver remote to turn satellite receiver on. Determine
correct elevation angle by entering the ZIP code for your location into receiver
(refer to receiver manual).
3. On the positioner press [UP/DOWN] arrow button until Search DSS
appears on the positioner screen, Figure 12.
1. Press UP/DOWN arrow
buttons to get Search DSS
on screen
Figure 12
4. Press [SELECT A] to enter the search function, Figure 12. (Press
[SELECT B] if Search DSS is bottom option on screen.
5. Press [SELECT B] Enter elevation, Figure 13.
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
2. Press SELECT A
Search DSS
Park
Finding the Satellite
Method 2:
Entering the Elevation
NOTE: SELECT A chooses
top option, SELECT B
chooses bottom option.
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Figure 13
3. Press SELECT B
Select a City
Enter Elevation
