MANUAL MOVEMENT
NOTE: All commands will be shown in bold with brackets, example
[SELECT A].
Manual Movement: This function allows you to manually move the antenna.
This feature is not normally used. Since the satellite signals are digital, once
the system acquires the signal, you cannot improve the picture, only increase
the signal strength. To manually move the antenna, proceed as follows:
NOTE: To manually lower the antenna to the travel position, refer to the
Troubleshooting Manual.
1. Press [UP/DOWN] arrow until Manual Move is displayed on positioner.
See Figure 26.
2. Press [SELECT A or B] Manual Move, see Figure 26.
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
1. Press UP/DOWN arrow
buttons to get Manual Move
on screen
Figure 26
2. Press SELECT A or B as
appropriate
Manual Move
Edit
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Figure 27
4. Press SELECT A to exit
Manual Move
3. Press UP to raise antenna
3. Press LEFT
to move antenna
to the left
3. Press DOWN
to lower antenna
Az(3) = XXXXX
El (3) = XXXXX
XXX
3. Press RIGHT
to move antenna
to the right
3. Press [ARROW BUTTONS] to move antenna in desired direction/position,
see Figure 27. Figure 28 shows what the various numbers indicate on the
positioner display.
