MOUNT ASSEMBLY
INDEX PART DESCRIPTION QTY
NO. NUMBER
2762832 Mount Assembly 1
1 3710300 Mount Base Stiffener 1
2 2160218 10-32 Nut 10
3 2762835 Rotation Switch Assembly 1
4 2160194 #10 x 1/2" Hex Head Bolt 6
5 2200946 Mount Base, White 1
6 3710260 Rotate Stop Ring 1
7 2160819 Spring 1
8 2200140 Rotation Drive Belt 1
9 3710261 Fixed Stop Ring 1
10 2201848 Rotation Pulley 1
11 2160185 10-32 x 3/8" Hex Head Bolt 19
12 3711303 Rotate Motor Tensioner 1
13 2762838 Rotation Motor Assembly 1
14 2160037 1/2" Flat Washer 1
15 2180509 Oil Lube Bushing 2
16 3710294 Stiffener Ring 1
17 2160223 3/8-32 Hex Nut 1
18 3200206 Boot Collar 1
19 2360060 F-8100 Male-to-Male F-connector 1
20 2200944 Top Cover, White 1
21 2200141 Elevation Drive Belt 1
22 2200850 Elevation Pulley 2
23 2160699 E-Clip 2
24 2762836 Elevation Switch Assembly 1
25 3711304 Elevation Motor Tensioner 1
26 2590345 Lift Arm Shaft 1
27 2200851 Seal 2
28 2762837 Elevation Motor Assembly 1
29 2160182 10-32 x 3/4" Phillips Head Screw 4
*NS 2753018 LNBF Coax Cable Jumper 4' RG-6 1
*NS - Part not shown for clarity
