62
Test LNB
To test the LNB, proceed as follows:
1. Turn receiver ON. Make sure antenna is not pointed at a satellite (no
picture or signal).
2. Access Edit Menu, press [UP/DOWN] arrow buttons until Edit is displayed
on positioner display. See Figure 21.
3. Press [SELECT A or B] as appropriate to enter Edit Menu. See
Figure 21.
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
1. Press UP/DOWN arrow
buttons to get Manual Move
on screen
Figure 21
2. Press SELECT A or B as
appropriate
Edit
Search DSS
Model RD-9900 PINNACLE
POSITIONER
by WINEGARD
SELECT B
SELECT A
Figure 22
3. Press UP button until
3000 is displayed
4. Press SELECT A to enter
code
Enter Code: 3000
4. Press [UP] arrow button until 3000 is displayed. See Figure 22.
5. Press [SELECT A] to enter code. See Figure 22.
