Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at www.wayne-dalton.com
3
Package Contents
DOOR sECTIONs (as REquIRED)
(2) VERTICal
TRaCk Rh/lh
(2) quICk INsTall Rh/lh
FlaGaNGlE (as REquIRED)
(2) Fully aDjusTablE Rh/lh
FlaGaNGlE (as REquIRED) (2) hORIzONTal TRaCk Rh/lh
NOTE: DEPENDING ON ThE DOOR MODEl, sOME PaRTs lIsTED WIll NOT bE suPPlIED IF NOT
NECEssaRy. REaR suPPORTs May OR May NOT bE INCluDED WITh yOuR DOOR.
ROllERs
(as REquIRED)
(2) hORIzONTal aNGlE
(80” OR 94”)
(as REquIRED)
(2) TOP bRaCkET basE
WEaThER sEal & NaIls
(IF INCluDED)
© Copyright 2006 Wayne-Dalton Corp. Part No. 325116 NEW 2/1/2006
Torsion Spring
Installation Instructions and Owners Manual
9800 Series
IMPORTANT NOTICE! Read these instructions carefully before
attempting installation. If in question about
any of the procedures, do not perform the
work. Instead, have a qualified door agency
do the installation or repairs.
MaNual
q.I. jaMb bRaCkETs
(as REquIRED)
RIGhT aND lEFT CablE
assEMblIEs
(1) CENTER bRaCkET (1) CENTER bRaCkET
bushING
END bEaRING bRaCkET
DOOR sTOP & NaIls
(IF INCluDED)
RIGhT & lEFT
DRuMs Rh/lh TORsION
sPRINGs (as REquIRED)
(2) TOP bRaCkET slIDE
(1) OPERaTOR bRaCkET
1/4”-14 x 5/8” sElF TaPPING
sCREW (as REquIRED)
(2) 3/8”-16 x 3/4”
TRuss hEaD bOlT
5/16” x 1 5/8” hEx hEaD
laG sCREW
(6) 3/8”- 16 hEx NuT
(as REquIRED)
5/16” x 1 5/8” TaMPER REsIsTaNT
laG sCREW (as REquIRED)
(4) 1/4”-20 x 5/8”
CaRRIaGE bOlTs
1/4”- 20 FlaNGED hEx
NuT (as REquIRED)
(2) 3/8”- 16 x 1-1/2” hEx
hEaD bOlT
(1) TORsION TubE
1/4” - 20 x 9/16” TRaCk bOlT
Pull ROPE &
sCREW EyE
(IF INCluDED)
F.a. jaMb bRaCkETs
(as REquIRED)
(8) 1/4”-20 x 9/16” laRGE
hEaD RIbbED TRaCk bOlTs
(as REquIRED)
1/4”-20 x 7/8” sElF DRIllING
sCREW (as REquIRED)
PRE-INST
ALLA
TION
