Tools Needed:
Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at www.wayne-dalton.com
16
lOCk sECTION
Stacking Sections
NOTE: For door section identification
see page 4.
NOTE: Make sure hinge leafs are flipped
down, when stacking another section
on top.
Place rollers in hinge tubes of the
second section (lock section). With
assistance, lift second section and
guide rollers into the vertical tracks.
align vertical marks in the upper
alignment sticker, with the lower
alignment sticker on right hand side
on the back of door. keep sections
aligned and fasten hinges to connect
the sections using 1/4” - 14 x 5/8”
self-tapping screws. Repeat for other
section(s) except top section.
IMPORTANT: WhEN sECuRING ThE END
hINGEs TO ThE sECTIONs WITh 1/4”
- 14 x 5/8” sElF-TaPPING sCREWs,
ENsuRE ThEy aRE aTTaChED as
shOWN IN ThE IllusTRaTIONs abOVE.
IMPORTANT: Push & hOlD ThE hINGE
lEaFs aGaINsT sECTION WhIlE
sECuRING WITh 1/4” - 14 x 5/8”
sElF-TaPPING sCREWs. END hINGEs
haVE (2) sCREWs aND INTERMEDIaTE
hINGEs haVE (3) sCREWs.
NOTE: Install lock at this time (sold
separately) see instructions in
OPTIONal sIDElOCk INsTallaTION on
page 29.
9
Power Drill
7/16” socket
Driver
(2) 1/4” - 14 x 5/8”
sElF-TaPPING sCREWs
END hINGEs (lEFT haND shOWN, RIGhT hINGE syMMETRICally OPPOsITE)
INTERMEDIaTE hINGEs
(3) 1/4” - 14 x 5/8”
sElF-TaPPING
sCREWs
32 79 85 N EW 9 -0 4- 06
32 79 85 N EW 9 -0 4- 06
INTERMEDIaTE hINGE
(3) 1/4” - 14 x 5/8” sElF-TaPPING sCREWs
RIGhT END hINGE
32 79 85 N EW 9 -0 4- 06
32 79 85 N EW 9 -0 4- 06
(2) 1/4” - 14 x 5/8”
sElF-TaPPING sCREWs
lEFT END hINGE
32 79 85 N EW 9 -0 4- 06
32 79 85 N EW 9 -0 4- 06
(2) 1/4” - 14 x 5/8”
sElF-TaPPING sCREWs
alIGNMENT
sTICkERs
