Tools Needed:
Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at www.wayne-dalton.com
20
NOTE: If you have fully adjustable
flagangle, skip this step and complete
step 14.
To install horizontal track, place the
curved end over the top roller. align
key slot of the horizontal track with the
quick install tab of the flagangle. Push
curved portion of horizontal track down
to lock in place.
DO NOT RaIsE DOOR uNTIl
hORIzONTal TRaCks aRE sE CuRED
aT REaR, as OuTlINED IN sTEP 33, OR
DOOR COulD Fall FROM OVERhEaD
POsI TION CausING sEVERE OR FaTal
INjuRy.
level the horizontal track assembly and
bolt the horizontal angle to the slot in
the flagangle using (1) 3/8” - 16 x 3/4”
truss head bolt and (1) 3/8” - 16 hex
nut. Repeat for other side. Remove the
nail that was temporarily holding the
top section in place, installed in step
12.
IMPORTANT: FaIluRE TO REMOVE NaIl
bEFORE aTTEMPTING TO RaIsE DOOR
COulD CausE PERMaNENT DaMaGE
TO TOP sECTION.
NOTE: If an idrive ® opener will be
installed, position horizontal tracks
slightly above level.
NOTE: after completing this step,
continue with step 15.
13
WARNING
3/8” - 16 x 3/4”
TRuss hEaD bOlT
3/8” - 16 hEx NuT
hORIzONTal
TRaCk
hORIzONTal aNGlE
kEy slOT
quICk
INsTall
Tab
hORIzONTal
TRaCk
VERTICal
TRaCk
FlaGaNGlE
13
9/16” socket
Ratchet Wrench
9/16” Wrench
level
kEy slOT
quICk
INsTall
Tab
hORIzONTal
TRaCk
VERTICal
TRaCk
FlaGaNGlE
FlaGaNGlE
Attaching horizontal Track to
quick Install flagangle
