Tools Needed:

Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.

To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at

www.wayne-dalton.com

PRIOR TO WINDING OR MakING
aDjusTMENTs TO ThE sPRINGs,
ENsuRE yOu’RE WINDING IN ThE
PROPER DIRECTION as sTaTED IN ThE
INsTallaTION INsTRuCTIONs.
OThERWIsE ThE sPRING FITTINGs May
RElEasE FROM sPRING IF NOT WOuND
IN ThE PROPER DIRECTION aND COulD
REsulT IN sEVERE OR FaTal INjuRy.

To adjust spring tension, fully close

door. apply locking pliers to track above

third roller. Insert a winding bar into

the winding cone. Push upward on the

winding bar while carefully loosening

the set screws in the winding cone.

bE PREPaRED TO suPPORT ThE Full

FORCE OF ThE TORsION sPRING ONCE

ThE sET sCREWs aRE lOOsE. Carefully

adjust spring tension 1/4 turn. Retighten

both set screws in the winding cone and

repeat for the other side. Recheck door

balance DO NOT aDjusT MORE ThaN

1/2 TuRN FROM ThE RECOMMENDED

NuMbER OF TuRNs. If door still does not

balance correctly, contact a qualified door

agency.

If the door still does not operate easily,

lower the door into the closed position,

uNWIND ThE sPRING(s) Fully (Refer to

“P1” on page 6 “Torsion spring Removal

For standard lift” and recheck the

following the items:

1.) Check the door for level.

2.) Check the torsion tube for level.

3.) Check the track spacing.

4.) Check the counterbalance cables for

equal tension.

5.) Check the track for potential

obstruction of the rollers.

6.) Clamp locking pliers onto track and

rewind springs

IMPORTANT! IF DOOR sTIll DOEs NOT

OPERaTE PROPERly, ThEN CONTaCT a

qualIFIED DOOR aGENCy.

Rear Support Continued...

PERFORaTED aNGlE

(3) 5/16”
bOlTs & NuTs

hORIzONTal TRaCk

bOlT MusT ExTEND INTO
ThE TRaCk TO sERVE as
a ROllER sTOP

sOuND FRaMING MEMbERs

hORIzONTal TRaCk

bOlT MusT ExTEND INTO
ThE TRaCk TO sERVE as
a ROllER sTOP

jaMb

WEaThER

sEal

PERMaNENTly aTTaChED

WEaThER sEal OR DOOR sTOP

aNGlE bRaCE

PERFORaTED aNGlE -bOlTED
usING (2) 5/16” x 1-5/8” hEx
hEaD laG sCREWs TO CEIl-
ING MEMbER aND PaRallEl
TO DOOR

aNGlE bRaCE
