WIRING-MAIN HARNESS
86306300 CHARIOT BURNISHER 11/09/07
5-46
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86239170 41528 1
HARNESS,
BRAKE
2
86239190
41538
1
HARNESS, MAIN BRSHR
3 86239520 880446 1
HARNESS, HALL SENSOR
4 86260220 80875 3
WIRE4X30BK
5/16RINGX5/16RING
5 86009000 81131 1
WIRE4X9.5BK 5/16RINGX5/16RING
6
86260600
880445
1
WIRE, 4X36 RD 5/16 RING
7
86010860
880353
1
WIRE, 4X20 BK CTERM X 5/16 RING
8
86260580
880443
1
WIRE, 4X12 RD 5/16 RING
9
86261210
29204
1
DIODE ASM, 76008 X 76008
