Windsor Chariot iGloss Burnisher CB20 - Manual (Page 63)

DECK LIFT LINKAGE
86306300 CHARIOT BURNISHER 12/13/08 5-26
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86004870 48077 1 KNOB, 3.50 OD X 3/8-16 THRU HOLE
2 86254590 81247 1 SPACER, .500 OD X .391 ID X .300
3 86005690 57085 1 NUT, 3/8-16 HEX JAM
4 86253260 730348 1 SHAFT, PAD ADJ, UPPER
5 86270990 57090 2 NUT, 10-32 HEX NYLOCK SS
6 86234620 270107 1 COUPLER, PAD ADJ
7 86259410 87206 1 WASHER, THRUST .51 ID X 1 OD X .063
8 86071330 140846 1 BRKT, ARM SUPPORT RT
9 86248980 81438 1 PIN, CLEVIS 3/8 X 1.75 PLTD
10 86231330 14664 2 BUSH, BRZ FLG .63 X .75 X 1.0
11 86008670 80606 1 COTTER, 3/8” RING
12 86012130 - 1 ACTUATOR, 36VDC DBLSPD, NOOK
13 86071320 140845 1 BRKT, ARM SUPPORT LFT
14 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
15 86270830 57023 5 NUT, 5/16-18 HEX NYLOCK SS
16 86066980 149990 3 BAR, COMP. SPRING RETAINER
17 86255100 73443 1 SPRING, DIE COMP. 1.25 OD X 3.0 LG
18 86090360 87492 2 WASHER, SPRING RETAINER
19 86078730 51412 1 PLATE ADJUSTMENT ROD
20 86316620 - 4 NUT, 3/8-16 LG THN HEX SS *(1)
21 86316630 - 1 SHAFT, PAD ADJ. LOWER 3/8-16 *(1)
22 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS
23 86005810 57245 1 NUT, 1/4-20 HEX NYLOCK SS
24 86277470 70848 1 SCR, 5/16-18 X 1.5 CARRIAGE SS
25 86091830 140847 1 BRKT, ADJUSTMENT ARM
26 86254580 80835 1 SPACER, .32 ID X .71 OD X .79 L NYL
27 86316640 - 1 PIVOT, PAD ADJ L/H THD 3/8-16 *(1)
28 86248980 81438 1 PIN, CLEVIS 3/8 X 1.75 PLTD
29 86300150 - 1 LINK, ACTUATOR CONTROL ARM
30 86001660 41236 1 HUBCAP, 5/8” SHAFT
31 86274410 70195 2 SCR, 10-32 X 1.25 PPHMS SS
32 86010680 87030 2 WASHER, 3/8 ID X 3/4 OD NYLON
33 86249190 66826 1 PIVOT, PAD ADJUST, L/H THD
34 86253270 730349 1 SHAFT, PAD ADJ, LOWER
35 86272010 57310 4 NUT, 3/8-24 LH THN HEX SS
*SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
