WHEEL-FRONT BRAKE
86306300 CHARIOT BURNISHER 11/09/07 5-32
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86010790 87163 4 WASHER, 3/8 SPLIT LOCK PLTD
2 86275190 70377 4 SCR, 3/8-16 X 1.25 HHCS SS
3 86006170 66031 1 PIN, ROLL 1/8” X 3/4”L SS
4 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
5 86277320 70828 1 SCR, M10 X 30 HHCS
6 86233410 81270 1 CLAMP, 3/4 DIA CUSHION .406DIA
7 86005710 57105 4 NUT, 1/4-20 HEX W/STAR WASHER
8 86273740 70010 2 SCR, 1/4-20 X 1.50 HHCS
9 86008920 80889 2 BOOT, RUBBER TERM. ISOLATOR
10 86257490 76155 2 TERMINAL MOUNT
11 86006840 70390 2 SCR, 1/4-20 X 1 FHCS PLTD
12 86010630 87013 2 WASHER, 1/4 ID X 5/8 OD SS
13 86273340 00-000289 4 SCR, 8-32 X 3/8 SHCS SS
14 86001740 140816 1 BRAKE, 36VDC W/CONNECTOR
15 86270990 57090 3 NUT, 10-32 HEX NYLOCK SS
16 86301950 1 PLATE, BRAKE SPACER
17 86264930 27050 1 CABLE TIE, 3.5” UL/CSA
18 86301960 1 SKIRT, BRAKE
19 86010650 87018 3 WASHER, #10 X 9/16 OD
20 86274290 70162 3 SCR, 10-32 X 3/8 PPHMS SS
