Windsor Chariot iGloss Burnisher CB20 - Manual (Page 41)

CONTROL PANEL
86306300 CHARIOT BURNISHER 11/12/08 5-4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS
2 86273830 70020 2 SCR, 1/4-20 X 1/2 HHCS SS
3 86010780 87162 2 WASHER, 1/4 SPLIT LOCK
4 86274380 70192 2 SCR, M5 X 15 PPHMS PLTD
5 86277480 70850 3 SCR, 5/16-18 X 1/2 PTHMS SS
6 86070670 140722 1 BRKT, BATTERY CONNECTOR
7 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS
8 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
9 86255910 73659 2 STANDOFF, 1/4-20 X 1.0 HEX INS
10 86006850 70393 2 SET SCR, 1/4-20 X 1.25L
11 86237000 80688 1 FUSE, 80 AMP
12 86010630 87013 6 WASHER, 1/4 ID X 5/8 OD SS
13 86008920 80889 2 BOOT, RUBBER TERM. ISOLATOR
14 86007180 72160 1 SWITCH, EMERGENCY STOP
15 86270830 57023 3 NUT, 5/16-18 HEX NYLOCK SS
16 86005710 57105 4 NUT, 1/4-20 HEX W/STAR WASHER
17 86255900 73538 8 STANOFF, 6-32 X 5/8 HEX NYL
18 86223740 70872 2 SCR, 1/4-20 X .59 PPHMS SS C
19 86257140 72196 1 SWITCH ASM, SEALED PB RND GRN
20 86007190 72161 1 SWITCH KEY DPST
21 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER
22 86257110 72189 1 SWITCH, 4P3T FIXED POS ROCKER
23 86257280 81371 1 SWITCH, PUSH BUTTON
24 86246920 54131 1 METER, 0-70 AMP L2020B
25 86008900 80845 1 BOOT, SEAL-PUSH BUTTON 7/16-28
26 86002010 14942 1 BOOT, 3/8 CIRCUIT BREAKER
27 86273980 70066 2 SCR, 10-32 X 3/4 PPHMS
28 86246930 54144 1 METER, 36V BATTERY CHARGE LEVEL
29 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER
30 86251410 67506 1 RELAY, 15A 36V MINI
31 86226560 36082 1 GROMMET, 1/2 ID X 3/32 GROOVE
32 86249290 62283 1 PLATE, METER RETAINING
33 86237830 35264 1 GASKET, AMP METER
34A 86002760 270092 1 CONTROLLER, CHAIN DRIVE BASIC
FOR 29269 DRIVE UNIT
(CHAIN)
34B 86027740 27911 1 CONTROLLER, GEAR DRIVE BASIC
FOR 29276 DRIVE UNIT
(GEAR)
35 86005700 57104 3 NUT, 10-32 W/STAR WASHER PLTD
36 86006370 67315 1 RELAY, 36VDC 100AMP HVY DUTY
37 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
38 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
39 86010670 87029 2 WASHER, 5/16 FLAT SS
40 86271120 57125 2 NUT, 5/16-18 BRASS
41 86002000 14717 1 BREAKER, 3 AMP
42 86229770 140805 1 BLOCK, SHUNT MOUNT
43 86279300 87134 4 WASHER, #6 LOCK
44 86273990 70067 4 SCR, 6-32 X 3/8 PPHMS
45 86005530 54154 1 METER, 12-48 VDC LED HOUR
46 86001910 14606 1 BREAKER, 30A 50VDC CIRCUIT
47 86078170 61479 1 PANEL, BURNISHER
