FRAME-LOWER
86306300 CHARIOT BURNISHER 11/09/07 5-12
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86300060 - 1 FRAME, MAIN ASM WAS 34440
2 86088760 75458 1 TRAY, SLIDE, LEFT
3 86270830 57023 21 NUT, 5/16-18 HEX NYLOCK SS
4 86071430 140863 1 BRKT, BRACE, RGT FRONT
5 86071120 140811 1 BRKT, TIP BRACE, RIGHT, REAR
6 86010670 87029 5 WASHER, 5/16 FLAT SS
7 86064300 140790 2 PAD, TIPPING BAR
8 86070740 140730 1 BRKT, LINKAGE, RIGHT
9 86276070 70593 16 SCR, 5/16-18 X 3/4 CARRIAGE SS
10 86091420 05251 1 AXLE, REAR WELDMENT
11 86088750 75457 1 TRAY, SLIDE, RIGHT
12 86277470 70848 6 SCR, 5/16-18 X 1.5 CARRIAGE SS
13 86071130 140812 1 BRKT, TIP BRACE, LEFT, REAR
14 86070750 140731 1 BRKT, LINKAGE, LEFT
15 86070760 140733 1 BRKT, BRACE, LEFT FRONT
16 86279130 87083 4 WASHER, 5/16 SPLIT LICK PLTD
17 86197040 57264 4 NUT, 5/16-18 HEX ACORN PLTD
18 86079290 620097 2 PLATE, REAR COVER ADJ.
19 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
20 86271870 57290 4 NUT, 1/4-20 HEX NYLOCK THIN SS
21 86276950 70772 4 SCR, 1/4-20 X 3/4 CARRIAGE SS
22 86079320 620101 2 PLATE, PAD RETAINER
23 86277130 70795 2 SCR, 5/16-18 X 1.00 CARRIAGE SS
24 86276910 70754 1 SCR, 5/16-18 X 3 HHCS SS NP
25 86001350 140390 2 BUSHING, SPANNER .435 X 1.10
26 86011020 89202 2 WHEEL, 3” DIA CUSHION RUBBER
27 86300100 - 1 BRKT, WHEEL MOUNT
