630-630-0 pg 5-10 and 5-11, Filter – Windsor Chariot iGloss Burnisher CB20 User Manual
Page 47
FILTER
86306300 CHARIOT BURNISHER 11/09/07
5-10
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86006590
70088
6
SCR, 10-32 X 1/2 PPHMS SS
2
86270320
39729
1
HOSE ASM, 1.5 BLK VAC X 36
3
86002840
27282
1
CUFF, 1.5 SLIP X 1.5 HOSE
4
86072500
14398
1
BRKT, FILTER COVER LATCH
5
86002380
20046
1
CLAMP, 2.25” WORM GEAR
6
86079280
620094
1
PLATE, FAN/BAG, MOUNT
7
86270970
57081
5
NUT, 10-32 CAPTIVE J-TYPE
8
86276890
70752
2
SCR, 5/16-18 X 3/4 PTHMS SS
9
86079250
620091
1
PLATE, FAN/BAG MOUNT
10
86270990
57090
4
NUT, 10-32 HEX NYLOCK SS
11
86271820
57270
2
NUT, 5/16-18 CAPTIVE “J” PLTD
12 86063790 27880 1 COVER
FILTER
13
86072510
14399
1
BRKT, FILTER COVER HINGE
14
86284870
2003SM
-
SM FILTER BAG PACKS 10/PKG
