STEERING
86306300 CHARIOT BURNISHER 11/09/07
5-28
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86271610
57228
1
NUT, 5/8-16 HEX NYLOCK THN
2 86234810 27945 1
COVER,
STEERING
WHEEL
3
86259610
730117
1
WHEEL, STEERING 40 SPLINE HUB
4
86224050
730318
1
SHAFT, UPPER STEERING
5 86228790 09111 1
BEARING,
FLANGE .88ODX.75IDX.75
6
86091740
140720
1
BRKT, UPPER STEERING
7
86270830
57023
4
NUT, 5/16-18 HEX NYLOCK SS
8
86005610
57016
1
NUT, 7/8 DIA PUSHLOCK
9
86219600
45012
1
JOINT, UNIVERSAL FEMALE
10
86272900
67416
1
RING, 3/4” KLIP
11
86224060
730319
1
SHAFT, LOWER STEERING
12
86219650
48110
1
KEY, 5MM SQ X 39MM L
13
86228670
09072
1
BEARING, 3/4” BORE FLANGED
14
86276070
70593
4
SCR, 5/16-18 X 3/4 CARRIAGE SS
15 86224800 730315 2 SPROCKET,
STEERING
SHAFT
16
86010670
87029
2
WASHER, 5/16 FLAT SS
17
86135970
48045
1
KEY, 3/16 SQ X 5/8 LONG
18
86275190
70377
1
SCR, 3/8-16 X 1.25 HHCS SS
19
86008610
80595
2
FLANGE, BEARING PRESS STEEL
20
86001030
09148
1
BEARING, BALL 3/4 BORE SPHERED
21
86224320
730221
1
SPACER, .63 OD X .385ID X .64L
22
86224810
730316
1
SPROCKET, DRIVE WHEEL STEERING
23
86005630
57022
2
NUT, 3/8-16 HEX NYLOCK THIN SS
24
86300190
-
1
CHAIN, 12.7MM PITCH
25
86278940
87008
2
WASHER, 1/4 ID X 1-1/4OD
26
86010780
87162
1
WASHER, 1/4 SPLIT LOCK PLTD
27
86274330
70175
1
SCR, M6 X 20HHMS PLTD
28
86279130
87083
2
WASHER, 5/16 SPLIT LOCK
29
86253200
70806
1
SET SCR, M6 X 25 NP
SERVICE
ONLY
30
86279620
87200
1
WASHER, .4 ID X 1.3 OD NYLON
31 86002710 270076 1 CHAIN
TENSIONER
32 86224270 730293 1 SLEEVE,
CHAIN TENSIONER
33
86275990
70577
1
SCR, 3/8-16 X 3.5 SHCS PLTD
-
86232780
279001
-
CHAIN, MASTERLINK 12.7MM
SERVICE
ONLY
-
86232770
279000
-
CHAIN, OFF-SET LINK 12.7MM
SERVICE
ONLY
