DRIVE CONTROLS
86306300 CHARIOT BURNISHER 11/09/07 3-6
1. Key Switch
2. Emergency Stop/Brake Switch
3. Directional Control Switch
4. Throttle Pedal
5. Operator Presence Pedal
6. Speed Control Switch
7. Drive Reset Switch
8. Horn Button
9. Steering Wheel
10. Battery Discharge
Indicator
11. Hour Meter
1. KEY SWITCH
Controls the power for machine functions.
To turn the machine power on, rotate key clockwise.
To turn the machine off, rotate key counterclockwise.
2. EMERGENCY STOP/BRAKE SWITCH
This safety feature is designed to cut all power to the machine at any time and apply parking brake.
To shut the machine power off, push the Emergency Stop Switch, this will also engage the parking brake and
cause the machine to stop immediately.
To reset the machine, rotate the switch clockwise.
3. DIRECTIONAL CONTROL SWITCH
Controls the direction of travel of the vehicle. The position of the switch indicates direction of travel.
To travel forward, press the top of the switch.
To travel in reverse, press the bottom of the switch.
4. THROTTLE PEDAL
Controls the speed of the vehicle within the speed control setting selected. Pressing the pedal causes the
machine to travel in the direction selected by the Directional Control Switch.
To increase speed, increase pressure on the pedal.
To decrease speed, decrease pressure on the pedal.
5. OPERATOR PRESENCE PEDAL
This safety feature is designed to ensure that the operator has their left foot on pedal platform whenever
machine is moving. The operator must have left foot on Operator Presence Pedal for machine to move.
