Windsor Chariot iGloss Burnisher CB20 - Manual (Page 61)

DECK LIFT MECHANISM
86306300 CHARIOT BURNISHER 01/17/09 5-24
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86271840 57285 3 NUT, 5/16-18 HEX NYLOCK THIN SS
2 86279130 87083 3 WASHER, 5/16 SPLIT LOCK PLTD
3 86135970 48045 1 KEY, 3/16 SQ X 5/8 LONG
4 86028170 53269 1 MOTOR, 36VDC 4HP 2000RPM
5 86277030 70780 4 SCR, 5/16-18 X 1.25 CARRIAGE SS
6 86006560 70083 2 SCR, 5/16-18 X 1 HHCS SS
7 86010670 87029 4 WASHER 5/16 FLAT SS
8 86231090 80809 2 BUMPER, RUBBER 5/16” ID X 1.50
9 86071480 140868 1 BRKT, MOTOR MOUNT
10 86270830 57023 14 NUT, 5/16-18 HEX NYLOCK SS
11 86228840 09124 8 BEARING, FLANGED .314 ID X .502 OD
12 86259400 87205 8 WASHER, .51 ID X 1 ODBRO
13 86083510 66834 1 PLATE, MOTOR SPACER
14 86277130 70795 8 SCR, 5/16-18 X 1.00 CARRIAGE SS
15 86073440 149992 1 BRKT, SWITCH MOUNT
16 86026450 730352 1 SHROUD, 20 IN BURNISHER
INCLUDES BRUSH
STRIPS (730074)
17 86278910 87003 4 WASHER, 3/8 OD X 7/8 OD SS
18 86010790 87163 4 WASHER, 3/8 SPLIT LOCK
19 86276920 70755 4 SCR, 3/8-16 X 1 HHCS SS NP
20 86248280 64110 1 PAD DRIVER ASSEM 20”, .88 BORE INCLUDES 40 & 41
21 86254310 730355 1 SPACER, BURNISHER HUB
22 86277540 70863 1 SCR, 7/16-20 X 1 HHCS PLTD
23 86010710 87080 1 WASHER, .5 X 1.25 FLAT GR8 PLTD
24 86007780 73576 1 SPRING, COMP .60D X 2.0L X .045W
25 86270270 27721 2 CLIP, RETAINING 7/16
26 86223270 66482 1 PLUNGER, MICRO SWITCH
27 86276950 70772 2 SCR, 1/4-20 X 3/4 CARRIAGE SS
28 86276010 70580 2 SCR, 4-40 X 1.0 PPHMS
29 86072460 14387 1 BRKT, MIRCOSWITCH MOUNT
30 86087520 73456 2 SPACER, PLUNGER SWITCH
31 86007160 72157 1 SWITCH, 10A ROLLER MINI
32 86271280 57163 2 NUT, 4-40 W/STAR WASHER
33 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
34 86008670 80606 2 COTTER, 3/8” RING
35 86071470 140867 1 BRKT, HEAD ATTACH
36 86007020 70673 4 SCR, 5/16-18 X 1.25 HHCS SS
37 86300120 - 2 BRKT, HEAD ATTACH RT.
38 86216230 730074 - BRUSH, STRIP (PACKAGE OF 6)
39 86279650 87222 8 WASHER, SEAL 5/16 X 3/4 OD SS
40 86226930 51419 - LOCK, PAD DRIVER YELLOW
41 86161960 70222 - SCR, #8 X 1/2 PPHST BLK
42 86300130 - 2 BRKT, HEAD ATTACH LT.
43 86008920 80889 3 BOOT, RUBBER TERM. ISOLATOR **
*SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
