WHEEL-FRONT DRIVE, GEAR
86306300 CHARIOT BURNISHER 11/09/07 5-34
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86275190 70377 4 SCR, 3/8-16 X 1.25 HHCS SS
2 86010790 87163 4 WASHER, 3/8 SPLIT LOCK PLTD
3 86002830 27196 1 CABLE TIE, .375 X 24.7
4 86006170 66031 1 PIN, ROLL 1/8” X 3/4”L
5 86264930 27050 1 CABLE TIE, 3.5” UL/CSA
6 86301950 1 PLATE, BRAKE SPACER
7 86230010 140808 1 BRAKE, 36 VDC
8 86273340 00-000289 4 SCR, CAP 8-32 X 3/8 SHCS SS
9 86006840 70390 2 SCR, 1/4-20 X 1 FHCS PLTD
10 86257490 76155 2 TERMINAL MOUNT
11 86010630 87013 2 WASHER, 1/4 ID X 5/8 OD SS
12 86005710 57105 4 NUT, 1/4-20 HEX W/STAR WASHER
13 86273740 70010 2 SCR, 1/4-20 X 1.5 HHCS
14 86008920 80889 2 BOOT, RUBBER TERM. ISOLATOR
15 86233410 81270 1 CLAMP, 3/4 IDA CUSHION .406 DIA
16 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
17A 86011120 89262 1 WHEEL, 10 X 2, 5 X 1.06 W/KEYWAY
17B 86259920 89273 1 WHEEL, 10 X 2. 5 W/KEYWAY, GRY OPTION
18 86215440 140920 1 BOX, DRIVE UNIT
19 86223980 09134 3 SEALED BALL BRNG, 25MM X 52MM
20 86219420 41510 1 HUB STEERING
21 86223480 67450 2 RING, 52MM INTERNAL SNAP
22 86136640 70262 1 SCR, M8-1.25 X 20 HHMS PLTD
23 86277320 70828 10 SCR, M10 X 30 HHCS
24 86277340 70830 4 SCR, M6 X 15 HHCS BLK
25 86279690 87243 4 WASHER, M6 SPLIT LOCK BLK
26 86279710 87245 1 WASHER, M8 (2THK X 26 OD)
27 86225810 87506 1 WASHER, ANTI-ROTATION
28 86222720 620037 1 PLATE, BEARING RETAINER
29 86222760 620041 1 PLATE, DRIVE YOKE RH
30 86222770 620042 1 PLATE, BEARING COVER
31 86224020 730233 1 SHAFT ASM, DRIVE PIVOT
32 86224440 730387 1 SPACER, 25.51 ID X 45 OD X 39.1 L
33 86217730 29276 1 DRIVE MOTOR ASSEMBLY COMPLETE
- 86216210 53820 - BRUSH SET MOTOR, 53810 86005510
34 86270990 57090 3 NUT, 10-32 HEX NYLOCK SS
35 86301960 - 1 SKIRT, BRAKE
36 86010650 87018 3 WASHER, #10 X 9/16 OD
37 86274290 70162 3 SCR, 10-32 X 3/8 PPHMS SS
