3-21
Memory - erase
ERASE [not used alone]
:CFRQ Erase all Carrier Freq Stores (0-99)
:FULL Erase all Full Stores (100-199)
:RAM Erase all RAM Stores (200-299)
:ALL Erase all Stores (0-299)
Data type : None
Allowed suffices : None
Default suffix : None
Examples: ERASE:FULL
ERASE:ALL
Memory - sequencing
These commands enable you to step through the memory stores in a sequence. For triggering, refer
to 'Memory-triggering' below.
MSEQ [not used alone]
:MODE Select sequencing mode of operation. When a sequence is selected, the
user can step through the sequence using the RCL:UP and RCL:DN
commands. The sequence modes are SEQ1 to SEQ9, and the
sequencing can be disabled with the OFF parameter.
Data type : Character Program Data
Allowed suffices : None
Default suffix : None
Examples: MSEQ:MODE OFF
MSEQ:MODE SEQ2
:SEQ1...:SEQ9
:START Set the memory store for the start of the sequencing loop
:STOP Set the memory store for the end of the sequencing loop
Data type : Decimal Numeric Program Data
Allowed suffices : None
Default suffix : None
Example: MSEQ:SEQ2:START 50;STOP 70
MSEQ? Prepares message containing information on the current memory
sequencing mode in the following format:
:MSEQ:MODE
where: is character program data indicating the sequence
mode selection
Examples: :MSEQ:MODE SEQ4
:MSEQ:MODE OFF
MSEQ:SEQ1?
.....
MSEQ:SEQ9?
Prepares message containing information on the start and stop settings
of the given memory sequence in the following format:
:MSEQ:SEQn:START ;STOP
where n is between 1 and 9 inclusive
Example: :MSEQ:SEQ4:START 120;STOP 155
