VXI 3002 User Manual
Page 133
Annex-A-7
Table A-4 Pulse modulation on/off ratio test
Carrier frequency
(MHz)
Pulse mod. on/off
ratio (dB)
Measured value (dB)
0.145 >80
_______
1.1 >80
_______
10.1 >80
_______
32 >80
_______
101 >80
_______
321 >80
_______
1001 >80
_______
1199 >80
_______
1501 >70
_______
1801 >70
_______
2101 >70
_______
2399 >65
_______
Table A-5 Pulse modulation rise and fall time test
Result
(ns)
Rise time
<20 ns
_______
Fall time
<20 ns
_______
