VXI 3002 - Manual (Page 117)

5-42
Table 5-22 Internal FM deviation and distortion tests at 100 kHz deviation
FM Deviation Distortion
Carrier
frequency
(MHz)
FM deviation
min. (kHz)
Result (kHz) FM deviation
max. (kHz)
Distortion (%) Result (%)
10 95 _______ 105 <3% _______
10.144 95 _______ 105 <3% _______
10.292 95 _______ 105 <3% _______
10.441 95 _______ 105 <3% _______
10.592 95 _______ 105 <3% _______
10.746 95 _______ 105 <3% _______
10.901 95 _______ 105 <3% _______
11.059 95 _______ 105 <3% _______
11.22 95 _______ 105 <3% _______
11.382 95 _______ 105 <3% _______
11.547 95 _______ 105 <3% _______
11.714 95 _______ 105 <3% _______
11.884 95 _______ 105 <3% _______
12.056 95 _______ 105 <3% _______
12.23 95 _______ 105 <3% _______
12.5 95 _______ 105 <3% _______
12.587 95 _______ 105 <3% _______
12.77 95 _______ 105 <3% _______
12.995 95 _______ 105 <3% _______
13.143 95 _______ 105 <3% _______
13.333 95 _______ 105 <3% _______
Table 5-23 FM scale shape tests at 15 MHz carrier
FM deviation (kHz) FM deviation
min. (kHz)
Result (kHz) FM deviation
max. (kHz)
100 95 _______ 105
71 67.45 _______ 74.55
56 53.2 _______ 58.8
44 41.8 _______ 46.2
34 32.3 _______ 35.7
27 25.65 _______ 28.35
21 19.95 _______ 22.05
16 15.2 _______ 16.8
13 12.35 _______ 13.65
11 10.45 _______ 11.55
10 9.5 _______ 10.5
1 0.95 _______ 1.05
0.1 0.095 _______ 0.105
