5-28
Table 5-6 ALC linearity at 1200 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
−4 −5 _______ −3
−3 −4 _______ −2
−2 −3 _______ −1
−1 −2 _______ 0
0 −1 _______ +1
1 0 _______ +2
2 +1 _______ +3
3 +2 _______ +4
4 +3 _______ +5
5 +4 _______ +6
6 +5 _______ +7
7 +6 _______ +8
8 +7 _______ +9
9 +8 _______ +10
10 +9 _______ +11
11 +10 _______ +12
12 +11 _______ +13
12.1 +11.1 _______ +13.1
12.2 +11.2 _______ +13.2
12.3 +11.3 _______ +13.3
12.4 +11.4 _______ +13.4
12.5 +11.5 _______ +13.5
12.6 +11.6 _______ +13.6
12.7 +11.7 _______ +13.7
12.8 +11.8 _______ +13.8
12.9 +11.9 _______ +13.9
13 +12 _______ +14
14 +13 _______ +15
15 +14 _______ +16
16 +15 _______ +17
17 +16 _______ +18
18 +17 _______ +19
19 +18 _______ +20
20 +19 _______ +21
21 +20 _______ +22
22 +21 _______ +23
23 +22 _______ +24
24 +23 _______ +25
25 +24 _______ +26
