Table 5-29 Internal Φ M flatness test
Modulation
frequency (kHz)
Response
level min.
(dB)
Result (dB) Response
level max.
(dB)
0.1 −3 _______ +3
0.3 −3 _______ +3
1 − reference −
3 −3 _______ +3
10 −3 _______ +3
Table 5-30 Internal AM depth and distortion tests at − 4 dBm
AM depth 30% AM depth 80% Distortion
Carrier
frequency
(MHz)
min.
(%)
Result
(%)
max.
(%)
min.
(%)
Result
(%)
max.
(%)
Result at
30% depth
(<1.5%)
Result at
80% depth
(<2.5%)
1.5 28.5 _____ 31.5 76 _____ 84 _______ _______
6 28.5 _____ 31.5 76 _____ 84 _______ _______
9 28.5 _____ 31.5 76 _____ 84 _______ _______
11 28.5 _____ 31.5 76 _____ 84 _______ _______
20 28.5 _____ 31.5 76 _____ 84 _______ _______
50 28.5 _____ 31.5 76 _____ 84 _______ _______
100 28.5 _____ 31.5 76 _____ 84 _______ _______
200 28.5 _____ 31.5 76 _____ 84 _______ _______
500 28.5 _____ 31.5 76 _____ 84 _______ _______
Table 5-31 Internal AM depth and distortion tests at +7 dBm
AM depth 30% AM depth 80% Distortion
Carrier
frequency
(MHz)
min.
(%)
Result
(%)
max.
(%)
min.
(%)
Result
(%)
max.
(%)
Result at
30% depth
(<1.5%)
Result at
80% depth
(<2.5%)
1.5 28.5 _____ 31.5 76 _____ 84 _______ _______
6 28.5 _____ 31.5 76 _____ 84 _______ _______
9 28.5 _____ 31.5 76 _____ 84 _______ _______
11 28.5 _____ 31.5 76 _____ 84 _______ _______
20 28.5 _____ 31.5 76 _____ 84 _______ _______
50 28.5 _____ 31.5 76 _____ 84 _______ _______
100 28.5 _____ 31.5 76 _____ 84 _______ _______
200 28.5 _____ 31.5 76 _____ 84 _______ _______
500 28.5 _____ 31.5 76 _____ 84 _______ _______
