VXI 3002 - Manual (Page 125)

5-50
Table 5-40 Pulse modulation RF output at +14 dBm
Carrier frequency
(MHz)
RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
32 +12.5 _______ +15.5
60 +12.5 _______ +15.5
180 +12.5 _______ +15.5
300 +12.5 _______ +15.5
420 +12.5 _______ +15.5
540 +12.5 _______ +15.5
660 +12.5 _______ +15.5
780 +12.5 _______ +15.5
900 +12.5 _______ +15.5
1020 +12.5 _______ +15.5
1140 +12.5 _______ +15.5
1200 +12.5 _______ +15.5
1201 +11.5 _______ +16.5
1260 +11.5 _______ +16.5
1380 +11.5 _______ +16.5
1500 +11.5 _______ +16.5
1620 +11.5 _______ +16.5
1740 +11.5 _______ +16.5
1860 +11.5 _______ +16.5
1980 +11.5 _______ +16.5
2220 +11.5 _______ +16.5
2340 +11.5 _______ +16.5
2400 +11.5 _______ +16.5
Table 5-41 Pulse modulation on/off ratio test
Carrier frequency
(MHz)
Pulse mod. on/off
ratio (dB)
Measured value (dB)
32 >45 _______
100 >45 _______
320 >45 _______
1000 >45 _______
1200 >45 _______
1500 >40 _______
1800 >40 _______
2100 >40 _______
2400 >40 _______
