Using ViewRTU Tank Gate Interface
80 Installation and Operations Manual
Previous
The Previous push-button allows the user to step through multiple points of a point type. The
user is able to view the data in the Edit Point window of the previous point. Selecting Previous
at the first point number wraps to the last point number of the list.
Examine
The Examine push-button is used to go to the Point Connections window of the reference point
in the list box.
Opening a point connection window
•
Highlight the desired reference data parameter from the Edit Point window.
•
Click on the Examine push-button.
The user is taken to that reference point’s Point Connections window.
Exit
The Exit push-button exits the current point configuration and returns the user to the main
menu.
Download
The Download push-button allows the user to download the entire point data to the Tank Gate
Interface.
Upload
The Upload push-button allows the user to upload the entire point data from the Tank Gate
Interface.
7.6.3 To modify a Value
Figure 7-24:Edit Point dialog (adding a value)
