8215 L&J Tankway Communications Interface Module
Tank Gate Interface
16
Installation and Operations Manual
Figure 3-1: L&J Tankway Tank Gate Interface Module
3.2.1
ID DIP Switch (SW1)
The dip switch is used for setting the ID number (1-14). The ID is a binary number representing
the address of the 8317 TGI.
Table 3-1:
ID DIP Switch settings
Field wiring
terminal block (J3)
LED indicators (D1 – D6)
Surge/Shield
ground connector (J4)
External Power Connector
(+48 - 65 VDC) (J2)
+48-65 VDC power fuse
(1 A 250V TR5) (F1)
ID DIP Switch (SW1)
Transmit Line Fuse
(63 mA 250V TR5) (F2)
Firmware
Binary
8
4
2
1
Binary
8
4
2
1
Switch #
1
2
3
4
Switch #
1
2
3
4
Address 1
o
o
o
c
Address 8
c
o
o
o
Address 2
o
o
c
o
Address 9
c
o
o
c
Address 3
o
o
c
c
Address 10
c
o
c
o
Address 4
o
c
o
o
Address 11
c
o
c
c
Address 5
o
c
o
c
Address 12
c
c
o
o
Address 6
o
c
c
o
Address 13
c
c
o
c
Address 7
o
c
c
c
Address 14
c
c
c
o
Address 1 Shown
CLOSED
OPEN
1
2
3
4
