Software Description Tank Gate Interface
28 Installation and Operations Manual
In this example, the Modbus register map is configured according to the following table:
Table 4-2: Example Modbus register map
Data Address Parameter Comments
100-101 MSTX.00.Level Level is in IEEE Floating point format.
102-103 MSTX.01.Level
104-105
.
.
.
138-139 MSTX.02.Level
.
.
.
MSTX.19.Level
200-201 MSTX.00.Temp Temperature is in IEEE Floating Point
Format.
202-203 MSTX.01.Temp
204-205
.
.
.
238-239 MSTX.02.Temp
.
.
.
MSTX.19.Temp
300 MSTX.00.PntStatus PntStatus is in Integer format.
301 MSTX.01.PntStatus
302
.
.
.
.319
MSTX.02.PntStatus
.
.
.
.MSTX.19.PntStatus
